Ring Type Burner

Ring Type Burner
Ring Type Burner
Product Code : Ring Type Burner
Product Description

Ring Type Burner
Item Code: M-22AndM-35

Most appropriate for heavy heating requirements of commercial cooking and industries: general & pharmaceuticals and dairy. Produces lovely blue sunflower shaped flame; available in two capacities. These burners are recommended to be used at a pressure of 320 gm/cm2 (4. 5 psig), however this may be varied by ± 25%; the heat output being varied accordingly.
these burners are also known as m-22 or m-1 and m-35 or m-2 . Also available in model m50, m78

Cross section of ring type burner model m-35
Specifications: operation pressure: 320 gm/cm2 (4. 5 psig)



m-1 burner

m-2 burner

Consumption k cals/hr

      11,700

      18,550

  (kg/hr)

      1. 0

      1. 58

 BTU/hr rated heat output

      46,000

      73,000

Diameter of burner head

      60mm

      80mm

Height (adjustable)

      235 to 275mm

      260 to 280mm

connection 3/8? Bspm compression inlet burners in this model
